Student Extract Table in MaineStreet Campus Solutions

This table—containing the most detailed information—is a prime example of our MaineStreet data documentation. Although this page was originally created to aid in reporting, the information is crucial to the development of data marts and ultimately a data warehouse.

Extracted table of student information by institution, term, and student. This is the base extract for all other UM_STUD tables: UM_STUD_CENSUS, UM_STUD_CENS_VW, UM_STUD_EXT_ARC, UM_STUD_EXT_VW.

This table was created by the UMS to aid in student reporting by combining information from many tables, thus decreasing the number of joins and calculations required to retrieve the information you need. It also contains calculated fields that can make reporting much easier, however it is still very large, so using a view is most often preferable. This table is refreshed daily except for Sundays and it continues to capture changes to students until 3 months after the term end date..

Key	Record.Fieldname	Format	XLAT	Heading Text	Source Table
	ACADEMIC_LOAD - Academic Load	Char1	N	Acad Load	STDNT_CAR_TERM
	ACADEMIC_LOAD_DT - Academic Load Change Date	Date		Load Date	STDNT_CAR_TERM
→	ACAD_CAREER - Academic Career	Char4	N	Career	STDNT_CAR_TERM
	ACAD_CAREER_FIRST - First Time in Career	Char1		First Time Car	STDNT_CAR_TERM
	ACAD_GROUP - Academic Group	Char5		Acad Group
	ACAD_GROUP_ADVIS - Academic Group of Advisor	Char5		Group	STDNT_CAR_TERM
	ACAD_LEVEL_BOT - Academic Level - Term Start	Char3		Strt Level	STDNT_CAR_TERM
	ACAD_LEVEL_EOT - Academic Level - Term End	Char3		End Level	STDNT_CAR_TERM
	ACAD_LEVEL_PROJ - Academic Level - Projected	Char3		Proj Level	STDNT_CAR_TERM
	ACAD_LOAD_APPR - Approved Academic Load	Char1	N	Acad Load	ACAD_PROG
→	ACAD_PLAN - Academic Plan	Char10		Acad Plan	From ACAD_PLAN table with corresponding EMPLID, ACAD_CAREER,, STDNT_CAR_NBR, and INSTITUTION fields
	ACAD_PLAN_TYPE - Academic Plan Type	Char3	N	Plan Type	ACAD_PLAN_TBL
→	ACAD_PROG - Academic Program	Char5		Acad Prog	From the ACAD_PROG table with corresponding EMPLID, ACAD_CAREER,, STDNT_CAR_NBR, and INSTITUTION fields
	ACAD_PROG_DESCR - Academic Program	Char30		Program
	ACAD_PROG_DUAL - Dual Academic Program	Char5		Dual Prog	ACAD_PROG
	ACAD_PROG_PRIMARY - Primary Academic Program	Char5		Prim Prog	STDNT_CAR_TERM
	ACAD_SUBPLAN_TYPE - Academic Sub-Plan Type	Char3	N	Sub-Pl Typ	ACAD_SUBPLN_TBL
	ACAD_SUB_PLAN - Academic Sub-Plan	Char10		Sub-Plan	ACAD_SUBPLAN
	ACAD_YEAR - Academic Year	Char4		Acad Year	STDNT_CAR_TERM
	ACTION_DT - Action Date	Date		Action Date	ACAD_PROG
	ADDRESS1 - Address Line 1	Char55		Address 1	`If the PS_ADDRESSES` `table` `has an active address ,the address` `is` `used. Otherwise` `used the fields` `from` `PS_PERSONAL_DATA.` `The value 'UK'(Unknown) is added on ADDRESS, CITY, and STATE fields when there is no address available.`
	ADDRESS2 - Address Line 2	Char55		Address 2	`If the PS_ADDRESSES` `table` `has an active address ,the address` `is` `used. Otherwise` `used the fields` `from` `PS_PERSONAL_DATA.`
	ADDRESS3 - Address Line 3	Char55		Address 3	`If the PS_ADDRESSES` `table` `has an active address ,the address` `is` `used. Otherwise` `used the fields` `from` `PS_PERSONAL_DATA.`
	ADDRESS4 - Address Line 4	Char55		Address 4	`If the PS_ADDRESSES` `table` `has an active address ,the address` `is` `used. Otherwise` `used the fields` `from` `PS_PERSONAL_DATA.`
	ADMISSION_EXCPT - Admission Residency Exception	Char5		Adm Excpt	RESIDENCY_OFF
	ADMISSION_RES - Admissions Residency	Char5		Admissions	RESIDENCY_OFF
→	ADMIT_TERM - Admit Term	Char4		Admit Term	ACAD_PROG
	ADMIT_TYPE - Admit Type	Char3		Admit Type	ADM_APPL_DATA
	ADM_APPL_CTR - Application Center	Char4		Appl Ctr	ADM_APPL_DATA
→	ADM_APPL_NBR - Application Nbr	Char8		Appl Nbr	ACAD_PROG
	ADVISOR_ID - Academic Advisor	Char11		Advisor
	ADVIS_STATUS - Advisement Status	Char4	N	Status	Part of degree audits which are not working for many campuses. Review after ERP reimplementation
	BILLING_CAREER - Billing Career	Char4		Bill Car	STDNT_CAR_TERM
	BIRTHDATE - Date of Birth	Date		Birthdate	PERSONAL_DATA
	BIRTHPLACE - Birth Location	Char30		Birthplace	PERSONAL_DATA
	BIRTHSTATE - Birth State	Char6		State	PERSONAL_DATA
	BIRTH_COUNTRY - BIRTH_COUNTRY	Char4		BIRTH_COUNTRY	PERSONAL_DATA
	CAMPUS - Campus	Char5		Campus	ACAD_PROG
	CITIZENSHIP_STATUS - Citizenship Status	Char1		Status	PS_CITIZENSHIP
	CITY - City	Char30		City	`If the PS_ADDRESSES` `table` `has an active address ,the address` `is` `used. Otherwise` `used the fields` `from` `PS_PERSONAL_DATA.` `The value 'UK'(Unknown) is added on ADDRESS, CITY, and STATE fields when there is no address available.`
	CLASS_RANK_NBR - Class Rank Nbr	Num5.0		Class Rank	STDNT_CAR_TERM
	CLASS_RANK_TOT - Class Rank Total	Num5.0		Of	STDNT_CAR_TERM
	COMPLETION_TERM - Completion Term	Char4		Compl Term	ACAD_PROG
	COUNTRY - Country	Char3		Country	`If the PS_ADDRESSES` `table` `has an active address ,the address` `is` `used. Otherwise` `used the fields` `from` `PS_PERSONAL_DATA.`
	COUNTRY_DESCR1 - Country Description	Char30		Country	PS_COUNTRY_TBL
	COUNTY - County	Char30		County	`If the PS_ADDRESSES` `table` `has an active address ,the address` `is` `used. Otherwise` `used the fields` `from` `PS_PERSONAL_DATA.`
	CUM_GPA - Cumulative GPA	Num6.3		GPA	STDNT_CAR_TERM
	CUM_RESIDENT_TERMS - Cumulative In Residence Terms	Num4.3		Cum Res	STDNT_CAR_TERM
	CUR_GPA - Current GPA	Num6.3		GPA
	CUR_RESIDENT_TERMS - Current In Residence Terms	Num4.3		Cur Res
	DECLARE_DT - Declare Date	Date		Decl Date
	DEGREE - Degree	Char8		Degree	ACAD_PLAN_TBL
	DEGR_CHKOUT_STAT - Degree Checkout Status	Char2	N	ChkoutStat	ACAD_PROG
	DT_OF_DEATH - Date of Death	Date		Death Date	PERSONAL_DATA When DT_OF_DEATH < 01/01/1901 or null, 01/01/1901 is entered.
	EDUCATION_LVL - Education Level	Char2	N	Education	DEGREE_TBL
	EFFECTIVE_TERM - Effective Term	Char4		Effective	RESIDENCY_OFF
	ELIG_TO_ENROLL - Eligible to Enroll	Char1		Elig Enrl	STDNT_CAR_TERM
	EMAIL_ADDR - Email Address	Char70		Email
→	EMPLID - Empl ID	Char11		ID	STDNT_CAR_TERM
	END_DATE - End Date	Date		End Date	STDNT_CAR_TERM
	ENRL_ON_TRANS_DT - Show Enrollment on Transcript	Date		Enrl Trans	STDNT_CAR_TERM
	ETHNIC_CATEGORY - Ethnic Category (this field has no data)	Char1	N	Ethnic Cat	ETHNIC_GRP_TBL - Ethnic Group Table
	ETHNIC_GROUP - Ethnic Group	Char1	N	Ethnic Grp	ETHNIC_GRP_TBL - Ethnic Group Table
	ETHNIC_GROUP_CD - Ethnic Group	Char8		Ethnic Grp	DIVERS_ETHNIC - Ethnic Diversity
	EXP_GRAD_TERM - Expected Graduation Term	Char4		Exp Grad	ACAD_PROG
	EXT_ORG_ID - External Org ID	Char11		Org ID	ADM_APPL_DATA `table` `is` `joined` `to` ACAD_PROG `table` `and` `returns LAST_SCH_ATTEND field as this EXT_ORG_ID field`
	FA_ELIGIBILITY - Program Eligibility Flag	Char1		Eligible	STDNT_CAR_TERM
	FA_LOAD - Financial Aid Load	Char1	N	FA Load	STDNT_CAR_TERM
	FA_STATS_CALC_DTTM - FA Stats Calc Date Time	DateTm		FA DTTM	STDNT_CAR_TERM
	FA_STATS_CALC_REQ - FA Stats Calculation Required	Char1		FA Calc	STDNT_CAR_TERM
	FIRST_NAME - First Name	Char30		First Name	PERSONAL_DATA
	FORM_OF_STUDY - Form of Study	Char4	N	Study Form	STDNT_CAR_TERM
	FULLY_ENRL_DT - Fully Enrolled Date	Date		Full Enrl	STDNT_CAR_TERM
	FULLY_GRADED_DT - Fully Graded Date	Date		Full Grded	STDNT_CAR_TERM
	GRADE_POINTS - Grade Points	Num7.3		Grd Points	STDNT_CAR_TERM
	GRADE_POINTS_FA - Financial Aid Grade Points	Num7.3		FA Grd Pt	STDNT_CAR_TERM
	GRADUATION_DT - Graduation Date	Date		Grad Dt	ADM_APPL_DATA - high school graduation
	HISP_LATINO - Person is Hispanic or Latino (Y or N)	Char1		Hisp or Latin
→	INSTITUTION - Academic Institution	Char5		Institution	STDNT_CAR_TERM
	INSTITUTION_DESCR - Institution	Char30		Institution	PS_INSTITUTION_TBL
	JOINT_PROG_APPR - Joint Program Approved	Char1		Joint Program	ACAD_PROG
	LAST_DATE_ATTENDED - Last Date of Attendance	Date		Last Date	STDNT_CAR_TERM
	LAST_NAME - Last Name	Char30		Last	PERSONAL_DATA
	LEVEL_LOAD_RULE - Academic Level Rule	Char5		Level Rule	ACAD_PROG_TBL (based on institution and ACAD_PROG)
	LOCK_IN_AMT - Lock In Amount	SNm15.2		Amount	STDNT_CAR_TERM
	LOCK_IN_DT - Lock In Date	Date		Date	STDNT_CAR_TERM
	MAR_STATUS - Marital Status	Char1	N	Mar Status	PERSONAL_DATA
	MAR_STATUS_DT - Marital Status Date	Date		Mar StatDt	PERSONAL_DATA When MAR_STATUS_DT < 01/01/1901 or null, 01/01/1901 is entered.
	MAX_AUDIT_UNIT - Max Audit Units	Num4.2		Max Audit	STDNT_CAR_TERM
	MAX_CRSE_COUNT - Max Total Courses	Num3.0		Total Crse	STDNT_CAR_TERM
	MAX_NOGPA_UNIT - Max No GPA Units	Num4.2		Max Grd Pt	STDNT_CAR_TERM
	MAX_TOTAL_UNIT - Max Total Units	Num4.2		Max Units	STDNT_CAR_TERM
	MAX_WAIT_UNIT - Max Wait List Units	Num4.2		Max Wait	STDNT_CAR_TERM
	MIDDLE_NAME - Middle Name	Char30		Middle	PERSONAL_DATA
	MIN_TOTAL_UNIT - Min Total Units	Num4.2		Min Units	STDNT_CAR_TERM
	NAME - Name	Char50		Name	PERSONAL_DATA
	NAME_PREFIX - Name Prefix	Char4		Prefix	PERSONAL_DATA
	NAME_SUFFIX - Name Suffix	Char15		Suffix	PERSONAL_DATA
	NSLDS_LOAN_YEAR - NSLDS Loan Year	Char1	N	Loan Year	STDNT_CAR_TERM
	OVRD_ACAD_LVL_ALL - Override All Academic Levels	Char1		Ovrd Lvls	STDNT_CAR_TERM
	OVRD_ACAD_LVL_PROJ - Override Projected Level	Char1		Ovrd Level	STDNT_CAR_TERM
	OVRD_BILL_UNITS - Override Billing Units	Char1		Ovrd Bill	STDNT_CAR_TERM
	OVRD_INIT_ADD_FEE - Override Initial Add Fees	Char1		Override Fee	STDNT_CAR_TERM
	OVRD_INIT_ENR_FEE - Override Initial Enroll Fee	Char1		Override Fee	STDNT_CAR_TERM
	OVRD_MAX_UNITS - Override Maximum Units	Char1		Ovrd Units	STDNT_CAR_TERM
	OVRD_TUIT_GROUP - Override Tuition Group	Char10		Ov Tuit Gp	STDNT_CAR_TERM
	OVRD_WDRW_SCHED - Override Withdrawal Schedule	Char8		Ov Wd Schd	STDNT_CAR_TERM
	PHONE - Telephone	Char24		Phone
	PIN_NUM - PIN Number	Num8.0		PIN Number
	PLAN_SEQUENCE - Plan Sequence	Num2.0		Plan Seq
	POSTAL - Postal Code	Char12		Postal	`If the PS_ADDRESSES` `table` `has an active address ,the address` `is` `used. Otherwise` `used the fields` `from` `PS_PERSONAL_DATA.`
	PROG_ACTION - Program Action	Char4	N	Prog Actn	ACAD_PROG
	PROG_REASON - Action Reason	Char4		Action Rsn	ACAD_PROG
	PROG_STATUS - Academic Program Status	Char4	N	Status	ACAD_PROG
	PROJ_BILL_UNT - Projected Bill Units	Num3.0		Bill Units	STDNT_CAR_TERM
	PRO_RATA_ELIGIBLE - Pro-Rata Eligible	Char1		Eligible	STDNT_CAR_TERM
	REFUND_PCT - Refund Percentage	Num4.2		Refund %	STDNT_CAR_TERM
	REFUND_SCHEME - Refund Scheme	Char8		Scheme	STDNT_CAR_TERM
	REGISTERED - Registered	Char1	N	Registered	STDNT_CAR_TERM
	REG_CARD_DATE - Registration Card Date	Date		Reg Card	STDNT_CAR_TERM
	REQ_TERM - Requirement Term	Char4		Req Term	ACAD_PROG
	RESET_CUM_STATS - Reset Cum Stats at Term Start	Char1		Cum Reset	STDNT_CAR_TERM
	RESIDENCY - Tuition Residency	Char5		Tuition Resid	Populated from the TUITION_RES field of the RESIDENCY_OFF table
	RESIDENCY_DT - Residency Date	Date		Res Date	RESIDENCY_OFF
	RESPONSE_DT - Response Date	Date		Date	From STDNT_RESPONSE table with max(RESPONSE_DT) and max (SEQNUM). The first row will be used when there are multiple rows.
	RESPONSE_REASON - Response Reason	Char4		Reason	From STDNT_RESPONSE table with max(RESPONSE_DT) and max (SEQNUM). The first row will be used when there are multiple rows.
	ROW_CHECK - ROW CHECK	Char1		ROW CHECK
	SEL_GROUP - Tuition Group	Char10		Group	STDNT_CAR_TERM
	SEX - Gender	Char1	N	Sex	PERSONAL_DATA
	SSR_ACTIVATION_DT - Term Activation Date	Date		Activation Date	STDNT_CAR_TERM
	START_DATE - Start Date for Gen Standing PO	Date		Start Date	STDNT_CAR_TERM
	STATE - State	Char6		State	`If the PS_ADDRESSES` `table` `has an active address ,the address` `is` `used. Otherwise` `used the fields` `from` `PS_PERSONAL_DATA.` `The value 'UK'(Unknown) is added on ADDRESS, CITY, and STATE fields when there is no address available.`
	STATE_DESCR1 - State Description	Char30		State	PS_STATE_TBL
	STATS_ON_TRANS_DT - Show Statistics on Transcript	Date		Stat Trans	STDNT_CAR_TERM
→	STDNT_CAR_NBR - Student Career Nbr	Num3.0		Career Nbr	STDNT_CAR_TERM
	STDNT_DEGR - Student Degree Nbr	Char2		Degree Nbr
→	STRM - Term	Char4		Term	STDNT_CAR_TERM
	STUDY_AGREEMENT - Study Agreement	Char10		Agreement	STDNT_CAR_TERM
	TC_UNITS_ADJUST - TC Units Adjustment	Num6.3		TC Units Adjust	STDNT_CAR_TERM
	TERM_TYPE - Term Unit Type	Char1	N	Term Type	STDNT_CAR_TERM
	TOT_AUDIT - Total Audited	Num6.3		Audit	STDNT_CAR_TERM
	TOT_CUMULATIVE - Total Cumulative Units	Num6.3		Total	STDNT_CAR_TERM
	TOT_GRADE_POINTS - Total Grade Points	Num7.3		Grade Points
	TOT_GRD_POINTS_FA - Total Fin Aid Grade Points	Num7.3		Tot FA Grd	STDNT_CAR_TERM
	TOT_INPROG_GPA - Total In Progress - GPA	Num6.3		In Pr GPA	STDNT_CAR_TERM
	TOT_INPROG_NOGPA - Total In Progress -Not for GPA	Num6.3		InPr NoGPA	STDNT_CAR_TERM
	TOT_OTHER - Total from Other Credit	Num6.3		Other	STDNT_CAR_TERM
	TOT_PASSD_FA - Total Fin Aid Units Passed	Num6.3		Pass FA	STDNT_CAR_TERM
	TOT_PASSD_GPA - Total Passed Toward GPA	Num6.3		Pass GPA	STDNT_CAR_TERM
	TOT_PASSD_NOGPA - Total Passed Not Toward GPA	Num6.3		PassNoGPA	STDNT_CAR_TERM
	TOT_PASSD_PRGRSS - Total Passed for Progress	Num6.3		Pass Prgrs	STDNT_CAR_TERM
	TOT_TAKEN_FA - Total Fin Aid Units Taken	Num6.3		Take FA	STDNT_CAR_TERM
	TOT_TAKEN_FA_GPA - Total Fin Aid Taken Toward GPA	Num6.3		Tot FA GPA	STDNT_CAR_TERM
	TOT_TAKEN_GPA - Total Taken Toward GPA	Num6.3		Take GPA	STDNT_CAR_TERM
	TOT_TAKEN_NOGPA - Total Taken Not Toward GPA	Num6.3		TakeNoGPA	STDNT_CAR_TERM
	TOT_TAKEN_PRGRSS - Total Taken for Progress	Num6.3		Take Prgrs	STDNT_CAR_TERM
	TOT_TEST_CREDIT - Total From Test Credit	Num6.3		Test	STDNT_CAR_TERM
	TOT_TRNSFR - Total Transferred	Num6.3		Transfer	STDNT_CAR_TERM
	TRF_GRADE_POINTS - Transfer Grade Points	Num7.3		Trnsfr Grd Pts	STDNT_CAR_TERM
	TRF_PASSED_GPA - Transfer Passed for GPA	Num6.3		TrnPasGPA	STDNT_CAR_TERM
	TRF_PASSED_NOGPA - Transfer Passed Not for GPA	Num6.3		TrnPasNGPA	STDNT_CAR_TERM
	TRF_RESIDENT_TERMS - Transfer In Residence Terms	Num4.3		Trf Res	STDNT_CAR_TERM
	TRF_TAKEN_GPA - Transfer Taken for GPA	Num6.3		TrnTakGPA	STDNT_CAR_TERM
	TRF_TAKEN_NOGPA - Transfer Taken Not for GPA	Num6.3		TrnTakNGPA	STDNT_CAR_TERM
	TUITION_RES_TERMS - Tuition Residency	Num4.3		Tuition Res.	STDNT_CAR_TERM RESIDENCY_OFF
	TUIT_CALC_DTTM - Tuition Calc Date Time	DateTm		TuitDTTM	STDNT_CAR_TERM
	TUIT_CALC_REQ - Tuition Calc Required	Char1		Calc Req	STDNT_CAR_TERM
	UM_ACAD_GRP_DESCR - Academic Group Descr	Char30		Academic Group
	UM_ACAD_LOAD_RC - Calculated Academic Load	Char1	N	Calc Acad Load	Case when STDNT_ENRL.acad_career <> 'NCRD' and STDNT_ENRL.UNT_PRGRSS >= 12 then 'F' when STDNT_ENRL.acad_career <> 'NCRD' and STDNT_CAR_TERM.acad_level_bot in ('GR' , 'MAS', 'PHD') and STDNT_ENRL.UNT_PRGRSS >= 6 then 'F' else 'P' end
	UM_ACAD_LVL_DESCR - Academic Level Description	Char30		Acad Level Desc	`description` `of` `ACAD_LEVEL_BOT`
	UM_ACAD_PLAN_DESCR - Academic Plan Description	Char30		Acad Plan Descr	ACAD_PLAN_TBL
	UM_ACAD_PROGP_DSC - Acad Prog Primary Descr	Char30		Acd Prg Prm Dsc
	UM_ACAD_SUBPLN_DSC - Academic Sub Plan Description	Char30		Acad Sub Descr	ACAD_SUBPLN_TBL
	UM_ADVISR_FST_NAME - Advisor First Name	Char30		Advisr Fst Name
	UM_ADVISR_LST_NAME - Advisor Last Name	Char30		Advisr Lst Name
	UM_ADVISR_MID_NAME - Advisor Middle Name	Char30		Advisr Mid Name
	UM_ADVISR_NAME_SFX - Advisor Name Suffix	Char15		Advisr Name Sfx
	UM_CITIZEN_STAT_OT - Citizenship Status Other	Char1		Citizn Stat Oth	PS_CITIZENSHIP This field is essentially unreliable for students with more than 1 foreign country listed in the CITIZENSHIP table.
	UM_COUNTRY_OTH - Country Other	Char3		Country Oth	PS_CITIZENSHIP This field is essentially unreliable for students with more than 1 foreign country listed in the CITIZENSHIP table.
	UM_COUNTRY_USA - Country is USA	Char3		Country USA	PS_CITIZENSHIP
	UM_EMAIL_HOM_ADDR - Email Home Address	Char70		Email Home Addr
	UM_ETHNIC_DESCR - Ethnic Description	Char50		Ethnic Descr	ETHNIC_GRP_TBL - Ethnic Group Table, DESC50 field
	UM_ETH_GRP_DESCR - Ethnic Group Descr	Char30		Eth Grp Descr
	UM_EXT_ORGID_DESCR - External Org ID Description	Char30		Ext Org ID Desc
	UM_FEES_PAID - Fees Paid	SNm8.0		Fees Paid	Although this field says "Fees Paid," the values are actually charges calculated from the CHARGES tree per Darren Michael, 10/19/09.
	UM_LAST_SCH_DESCR - Last School Attend Description	Char30		Lst School Desc	from PS_EXT_ORG_PRI_VW table based on EXT_ORG_ID field, which is LAST_SCH_ATTEND field on ADM_APPL_DATA table
	UM_LAST_SCH_TYPE - Last School Attended Type	Char3		Last School Typ	from EXT_ORG_TBL_ADM table based on EXT_ORG_ID field, which is LAST_SCH_ATTEND field on ADM_APPL_DATA table
	UM_MAX_ACT_COMP - Maximum ACT Comp	Num5.2		Max ACT Comp - Limited to last 5 years
	UM_MAX_ACT_ENGL - Maximum ACT English	Num5.2		Max ACT English - Limited to last 5 years
	UM_MAX_ACT_MATH - Maximum ACT Math	Num5.2		Max ACT Math - Limited to last 5 years
	UM_MAX_GRE_QUAN - Maximum Quantitative GRE	Num5.2		Max GRE QUAN
	UM_MAX_GRE_VERB - Maximum GRE Verbal	Num5.2		Max GRE VERB
	UM_MAX_SAT_ERWS - Max SAT ERWS	Num5.2		Max SAT ERWS - Limited to last 5 years
	UM_MAX_SAT_MATH - Maximum Sat Math	Num5.2		Max Sat Math - Limited to last 5 years
	UM_MAX_SAT_MSS - Max SAT MSS	Num5.2		Max SAT MSS - Limited to last 5 years
	UM_MAX_SAT_VERB - Maximum Sat Verbal	Num5.2		Max Sat Verbal - Limited to last 5 years
	UM_MAX_SAT_WRIT - Maximum SAT Write	Num5.2		Max SAT Write - Limited to last 5 years
	UM_MAX_TOEFL_COMPC - Maximum TOEFL COMPC	Num5.2		Max TOEFL COMPC
	UM_MAX_TOEFL_COMPI - Maximum TOEFL COMPI	Num5.2		Max TOEFL COMPI
	UM_MAX_TOEFL_COMPP - Maximum TOEFL COMPP	Num5.2		Max TOEFL COMPP
	UM_MIN_ACAD_PLAN - Academic Plan	Char10		Acad Plan
	UM_MIN_ACAD_PROG - Academic Program	Char5		Acad Prog
	UM_MIN_ACAD_SUBPLN - Academic Sub-Plan	Char10		Sub-Plan
	UM_MULTIPLE_ETHNIC - Multiple Ethnic Groups	Char1	N	Mutiple_Ethnic
	UM_NID_CAN - National ID Canada	Char20		NID Canada	Procedure: Get_NID Expand source select SB4.NATIONAL_ID, SB4.COUNTRY if &SB4.COUNTRY = 'USA' and &SB4.NATIONAL_ID > ' ' Let $Nid_Usa = &SB4.NATIONAL_ID end-if if &SB4.COUNTRY = 'CAN' and &SB4.NATIONAL_ID > ' ' Let $Nid_Can = &SB4.NATIONAL_ID end-if FROM PS_PERS_NID SB4
	UM_NID_USA - National Id USA	Char20		NID USA	Procedure: Get_NID Expand source select SB4.NATIONAL_ID, SB4.COUNTRY if &SB4.COUNTRY = 'USA' and &SB4.NATIONAL_ID > ' ' Let $Nid_Usa = &SB4.NATIONAL_ID end-if if &SB4.COUNTRY = 'CAN' and &SB4.NATIONAL_ID > ' ' Let $Nid_Can = &SB4.NATIONAL_ID end-if FROM PS_PERS_NID SB4
	UM_ORIG_ACAD_PLAN - ORIGINAL_ACAD_PLAN	Char10		ORIG_ACAD_PLAN
	UM_ORIG_ACAD_PROG - ORIGINAL_ACAD_PROG	Char5		ORIG_ACAD_PROG
	UM_PREVIOUS_NAME - Previous Name	Char50		Prev Name	Procedure: Get_Previous_Name Expand source select SB1.Name if &SB1.Name > ' ' Let $Previous_Name = &SB1.Name end-if FROM PS_NAMES SB1 WHERE SB1.NAME_TYPE = 'FR1' and SB1.EMPLID = &STA.EMPLID and SB1.EFFDT = (SELECT MAX(SB1_ED.EFFDT) FROM PS_NAMES SB1_ED WHERE SB1.EMPLID = SB1_ED.EMPLID AND SB1.NAME_TYPE = SB1_ED.NAME_TYPE AND SB1_ED.EFFDT <= [$input_date_M])
	UM_RSP_REASN_DESCR - Response Reason Descriptions	Char30		Resp Reason Des	from ps_resp_rsn_tbl
	UM_TUITION_PAID - Tuition Paid	SNm8.0		Tuition Paid	Although this field says "Tuition Paid," the values are actually charges calculated from the CHARGES tree per Darren Michael, 10/19/09.
	UM_UMS01_FLG - Ums01 Registered Flag	Char1		Ums01 Flag	Calculation based on the fields in STDNT_ENRL table
	UM_UMS01_UNITS - UMS01 Units	Num6.3		UMS01 Units	Calculation based on the fields in STDNT_ENRL table
	UM_UMS02_FLG - UMS02 Registered Flag	Char1		UMS02 Flag	Calculation based on the fields in STDNT_ENRL table
	UM_UMS02_UNITS - UMS02 Units	Num6.3		UMS02 Units	Calculation based on the fields in STDNT_ENRL table
	UM_UMS03_FLG - Ums03 Registered Flag	Char1		Ums03 Flag	Calculation based on the fields in STDNT_ENRL table
	UM_UMS03_UNITS - UMS03 Units	Num6.3		Ums03 Units	Calculation based on the fields in STDNT_ENRL table
	UM_UMS04_FLG - UMS04 Registered Flag	Char1		UMS04 Flag	Calculation based on the fields in STDNT_ENRL table
	UM_UMS04_UNITS - UMS04 Units	Num6.3		UMS04 Units	Calculation based on the fields in STDNT_ENRL table
	UM_UMS05_FLG - Ums05 Registered Flag	Char1		Ums05 Flag	Calculation based on the fields in STDNT_ENRL table
	UM_UMS05_UNITS - UMS05 Units	Num6.3		UMS05 Units	Calculation based on the fields in STDNT_ENRL table
	UM_UMS06_FLG - Ums06 Registered Flag	Char1		Ums06 Flag	Calculation based on the fields in STDNT_ENRL table
	UM_UMS06_UNITS - UMS06 Units	Num6.3		UMS06 Units	Calculation based on the fields in STDNT_ENRL table
	UM_UMS07_FLG - Ums07 Registered Flag	Char1		Ums07 Flag	Calculation based on the fields in STDNT_ENRL table
	UM_UMS07_UNITS - UMS07 Units	Num6.3		UMS07 Units	Calculation based on the fields in STDNT_ENRL table
	UM_UNT_DIST - Units Distance	Num10.3		Units Distance	Calculation based on the fields in STDNT_ENRL & CLASS_TBL tables
	UM_UNT_ITV - Itv Receive Units	Num10.3		Itv Receive Unt	Calculation based on the fields in STDNT_ENRL & CLASS_TBL tables
	UM_UNT_TAK_CAREER - Units Taken For Career	Num6.3		Unt Takn Career	Calculation based on the fields in STDNT_ENRL table
	UM_UNT_TAK_PRG_RC - Units Taken Progress Row Check	Num6.3		Units Taken Prg	Calculation based on the fields in STDNT_ENRL table
	UM_UNT_WEB - Web Units	Num10.3		Web Units	Calculation based on the fields in STDNT_ENRL & CLASS_TBL tables
	UNIT_MULTIPLIER - Unit Multiplier	Num5.4		Multiplier	STDNT_CAR_TERM
	UNTPRG_CHG_NSLC_DT - Unit Progrss Changed Date NSC	Date		Unit ChgDt NSC	STDNT_CAR_TERM
	UNT_AUDIT - Units Audited	Num6.3		Audit	STDNT_CAR_TERM
	UNT_INPROG_GPA - Units In Progress - GPA	Num6.3		InPr GPA	STDNT_CAR_TERM
	UNT_INPROG_NOGPA - Unit In Progress - Not for GPA	Num6.3		InPr NoGPA	STDNT_CAR_TERM
	UNT_OTHER - Units from Other Credit	Num6.3		Other	STDNT_CAR_TERM
	UNT_PASSD_FA - Fin Aid Progress Units Passed	Num6.3		FA Passed	STDNT_CAR_TERM
	UNT_PASSD_GPA - Units Passed Toward GPA	Num6.3		Pass GPA	STDNT_CAR_TERM
	UNT_PASSD_NOGPA - Units Passed Not Toward GPA	Num6.3		PassNoGPA	STDNT_CAR_TERM
	UNT_PASSD_PRGRSS - Units Passed for Progress	Num6.3		Pass Prgrs	STDNT_CAR_TERM
	UNT_TAKEN_FA - Fin Aid Progress Units Taken	Num6.3		FA Taken	STDNT_CAR_TERM
	UNT_TAKEN_FA_GPA - FA Units Taken Toward GPA	Num6.3		FA Units T	STDNT_CAR_TERM
	UNT_TAKEN_GPA - Units Taken Toward GPA	Num6.3		Take GPA	STDNT_CAR_TERM
	UNT_TAKEN_NOGPA - Units Taken Not Toward GPA	Num6.3		TakeNoGPA	STDNT_CAR_TERM
	UNT_TAKEN_PRGRSS - Units Taken for Progress	Num6.3		Take Prgrs	STDNT_CAR_TERM
	UNT_TERM_TOT - Total Term Units	Num6.3		Total	STDNT_CAR_TERM
	UNT_TEST_CREDIT - Units from Test Credit	Num6.3		Test	STDNT_CAR_TERM
	UNT_TRNSFR - Units Transferred	Num6.3		Transfer	STDNT_CAR_TERM
	VALIDATED - Election Validated	Char1		Validated
	VALIDATED_DT - Date Data Validated	Date		Date Validated
	WITHDRAW_CODE - Withdrawal \ Cancel	Char3	N	Wdraw Code	STDNT_CAR_TERM
	WITHDRAW_DATE - Withdrawal \ Cancel Date	Date		Wdraw Date	STDNT_CAR_TERM
	WITHDRAW_REASON - Withdrawal \ Cancel Reason	Char4	N	WithdrlRsn	STDNT_CAR_TERM

Data Dictionary Links

Clicking the linked (blue) fields in any table will take you to the Data Dictionary and provide you with more information about that field as well as field values if they are available.

UM_STUD_EXTRACT

Source Code

Click here for documentation of the SQL necessary to recreate the student extract. This will serve as a road map to recreating the extract as well as document the meaning of the fields that make up the UM_STUD_EXTRACT table.

File is .txt. Open with Notepad or a similar tool to retain formatting. Excel adds unwanted characters. If you have issues with access, please email DARTS@Maine.edu or request access through the link.

Tables Referenced

Below are the most important tables referenced for this extract.

XLATITEM

ACAD_PLAN

ACAD_PLAN_TBL

ADM_APPL_DATA

ACAD_PROG

ACAD_PROG_TBL

ACAD_GROUP_TBL

ADDRESSES

ACAD_SUBPLAN

ACAD_SUBPLN_TBL

CLASS_ATTRIBUTE

CITIZENSHIP

CLASS_TBL

COUNTRY_TBL

DIVERS_ETHNIC

DEGREE_TBL

EMAIL_ADDRESSES

EXT_ORG_PRI_VW

EXT_ORG_TBL_ADM

ETHNIC_GRP_TBL

ISIR_PARENT

ITEM_SF

INSTITUTION_TBL

NAMES

PERSONAL_DATA

PERS_NID

PROG_RSN_TBL

PERSON_COMMENT

RESIDENCY_OFF

RELATION_VW

RESP_RSN_TBL

STDNT_ADVR_HIST

STDNT_CAR_TERM

STDNT_ENRL

STDNT_GRPS

STDNT_RESPONSE

STATE_TBL

STDNT_TEST_COMP

TERM_VAL_TBL

TERM_TBL UM_ENRL_PIN

Data & Data Tool Resources

PeopleSoft Query

DARTS : UMS IT Data Resources

Data integrity for informed decisions and student success

UMS IT Resources

UMS Data Governance Issue Documentation
